Autel Autolink AL629

• The ABS/SRS/Engine/Transmission + CAN OBDII AutoLink AL629 is built to help you to determine why the Malfunction Indicator Light or the ABS/SRS warning light is on. Supporting all 10 test modes of OBDII test, AL629 provides you a complete diagnosis.

Autel AutoLink AL629 Features:

• AL629 Reads and erases DTCs for ABS, SRS, Engine and Transmission on most 1996 and newer major vehicle models (OBDII & CAN);
• A wide range of European, US and Asian vehicles: GM, Ford, Mazda, Toyota, Lexus, Scion, Suzuki, Peugeot, Citroen, Fiat, Abarth, Lancia, Alfa, Honda, Acura, Subaru, Nissan, Infiniti, Chrysler, Renault, Dacia, Land Rover, Jaguar, VW, Audi, Bugatti, Skoda, Seat, Bentley, Volvo and Porsche, etc.
• Retrieves generic (P0, P2, P3, and U0), manufacturer specific (P1, P3, and U1) codes and pending codes
• Turns off Check Engine Light (MIL), clears codes and resets monitors
• Reads, stores and plays back live PCM data stream and live sensor data
• Retrieves vehicle information (VIN, CALID and CVN)
• Views freeze frame data
• Graphs data
• TF memory card for data backup and software update
• Lifetime Free Update & One Year Warranty
• Autel AL629, US Stock, 3-day Fast Shipping
• Multilingual support – English, Spanish, French, etc.
• 2.8’’ LCD with 320X240 resolution
• Internet updatable via USB
• Prints data via PC

Autel AutoLink AL629 Specification：

Display:	2.8-inch LCD (320 x 240 dpi)
Connectivity:	USB mini 2.0, OBD II DB15
Operating Temp:	-10°C to 60°C (14°F to 140°F)
Storage Temp:	-20°C to 70°C (-4°F to 158 °F)
External Power:	8.0 to 18.0 V power provided via vehicle battery
Dimensions (LxWxH):	182.8 mm (7.2") x 90.9 mm (3.6") x 33.2 mm (1.3")
Net Weight:	247 g (0.544 lb.)

Autel AutoLink AL629 Package List:

• 1 x AL629 OBD Code Reader
• 1 x User Manual
• 1 x Carrying Case
• 1 x Quick Reference
• 1 x GuideMain cable
• 1 x TF card
• 1 x Mini USB Cable
